Level finder (20m) single level – green line Model SW-311G Mini Cross Line Laser Green Beams Laser Wavelength 510-530nm Laser Class Class 2 (IEC/EN60825-1/2014) Leveling Accuracy ±3mm/10m Horizontal/Vertical Accuracy ±3mm/10m Leveling/Compensation Range 4°±1° Working Distance (Line) 20m Working Distance (Line with Detector) No Operating Time Approximately>8 Hours IP Rating IP54 Operation Temperature Range -10 ℃ – 50 ℃ Storage Temperature Range -20 ℃ – 70 ℃ Power source 2*1.5V AA(not include) Product Dimension 65.4x75x76mm Product Weight 261g Package Size 135 x 125 x 80mm Package Weight 455g Packing Contents 1 X laser level( No battery )
1 X Magnetic pivoting base
1 X English User’s Manual
1 X Bag
laser level Green 2 lines self-leveling laser Leveler Vertical Horizontal Cross laser gren beam line measuring instrument
General Notes: • Press or slide locking switch to turn laser tool ON;short press to turn laser tool OFF when the laser tool is locked with pendulum.
Self-leveling Mode • It is enabled when the laser tool is switched to the unlocked position.
• It has laser beam(s) blink fast at 2 Hz when tool is out of self-leveling range.
• It allows proper use of tool’s full time pulse mode with laser detector.
Manual Mode • It is enabled when the pendulum lock is in its locked position to position the laser tool at various angles to project non-level straight lines.
• It disables self-leveling operations; Accuracy of the beam(s) is not guaranteed to be level, and laser beam(s) will blink about every 5 seconds.
SKU: SW-311 G
Categories: LASER LEVEL
